SFP-25G-LR-C Juniper SFP-28 25G-LR Transceiver
SFP-25G-LR-C Overview
Juniper SFP-28 25G-LR Transceiver
$1,681.00
Shipping calculated at checkout.
SFP-25G-LR-C Technical Specifications
Juniper SFP-28 25G-LR Transceiver
| Model Type | 25 Gigabit Ethernet |
|---|---|
| Transceiver Type | SFP28 |
| Connector | LC/PC |
| Fiber grade | SMF |
| Digital Diagnostic Monitoring | Transceiver temperature, Transceiver supply voltage, TX bias current, TX output power, RX received optical power |
| Signaling rate, each lane | 25.78125 GBd ± 100 ppm |
| Transmitter fibers | 1 |
| Transmitter wavelengths (range) | 1295 to 1325 nm |
| Receive lane wavelengths (range) | 1295 to 1325 nm |
| Side-mode suppression ratio (SMSR), (minimum) | 30 dB |
| Transmitter output power, each lane (minimum) | -7 dBm |
| Transmitter output power, each lane (maximum) | 2 dBm |
| Receiver input power, each lane (minimum) | -13.3 dBm |
| Stressed receiver sensitivity (OMA) each lane (maximum) | -9.5 dBm |
| Cable type | SMF |
| Core size/cladding | 9/125 µm |
| Fiber grade | SMF |
| Distance | 10 km |
