ONS-XC-10G-EP46.1 Technical Specifications
Cisco Edge Performance XFP Transceiver Module 10 GigE
Connectors
| Left Connector Type | LC single-mode |
|---|
Environmental Parameters
| Max Operating Temperature | :158 °F |
|---|---|
| Min Operating Temperature | :32 °F |
| Brand | Cisco Transceiver |
|---|---|
| Manufacturer | CISCO DS HARDWARE DIRECT |
| Model | Edge Performance |
| Packaged Quantity | :1 |
| Product Line | Cisco ONS |
Interface Provided
| Connector Qty | X 2 |
|---|---|
| Connector Type | LC single-mode |
| Qty | :1 |
| Type | DWDM |
Line Properties
| Line Rate | OC-192/STM-64 |
|---|
Miscellaneous
| Color Category | Gray |
|---|---|
| Mtbf | :2,711,000 hours |
Networking
| Cabling Type | DWDM |
|---|---|
| Connectivity Technology | Wired |
| Data Link Protocol | :10 Gigabit Ethernet |
| Data Transfer Rate | :10GBase |
| Form Factor | Plug-in module |
| Max Transfer Distance | :31.1 miles |
| Optical Wave Length | :1546.12 nm |
| Type | XFP transceiver module |
Dimensions & Weight
| Depth | :3.1 in |
|---|---|
| Height | :0.4 in |
| Width | :0.7 in |
