EX-SFP-1GE-LX Juniper SFP Mini-GBIC Transceiver Module
EX-SFP-1GE-LX Overview
SFP 1000Base-LX Gigabit Ethernet Optics, 1310nm for 10km transmit
$99.00
Shipping calculated at checkout.
EX-SFP-1GE-LX Technical Specifications
Juniper SFP Mini-GBIC Transceiver Module
| Manufacturer | Juniper |
|---|---|
| Device Type | Sfp (Mini-Gbic) Transceiver Module |
| Enclosure Type | Plug-In Module |
Networking
| Connectivity Technology | Wired |
|---|---|
| Cabling Type | 1000base-Lx |
| Data Link Protocol | Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 Nm |
| Max Transfer Distance | 6.2 Miles |
Expansion / Connectivity
| Interfaces | Network – Ethernet 1000base-Lx |
|---|---|
| Compatible Slots | Sfp (Mini-Gbic) |
| Signaling rate, each lane | 1.25 Gbps |
| Transmitter wavelengths (range) | 1270 nm to 1355 nm |
| Receive lane wavelengths (range) | 1270 nm to 1355 nm |
| Transmitter output power, each lane (minimum) | -9.5 dBm |
| Transmitter output power, each lane (maximum) | -3 dBm |
| Receiver input power, each lane (minimum) | -19 dBm |
| Receiver input power, each lane (maximum) | -3 dBm |
| Stressed receiver sensitivity (OMA) each lane (maximum) | -14.4 dBm |
