WUH722624ALE6L4 Western Digital Ultrastar 24TB SATA 6Gb/s 3.5-Inch Hard Drive

WUH722624ALE6L4 Overview

The Western Digital Ultrastar DC HC590 24TB (WUH722624ALE6L4) represents the cutting edge of high-density SATA storage, purpose-built for hyperscale data centers, cloud environments, and massive scale-out architectures. By integrating Western Digital’s innovative OptiNAND technology with UltraSMR (Shingled Magnetic Recording), this drive delivers an industry-leading 24TB of capacity in a standard 3.5-inch form factor. Designed to optimize Total Cost of Ownership (TCO), the HC590 allows data center architects to maximize storage density per rack while benefiting from the 10th-generation HelioSeal technology, which ensures exceptionally low power consumption and superior thermal reliability for 24/7 mission-critical operations.

$850.00

Shipping calculated at checkout.
or
SKU: WUH722624ALE6L4 Categories: Brand:

WUH722624ALE6L4 Technical Specifications

Western Digital Ultrastar DC HC590 24TB 7200RPM SATA 6Gb/s SE 512MB Cache 3.5-Inch Hard Drive

Manufacturer Western Digital
Manufacture Part Number WUH722624ALE6L4
Series Ultrastar DC HC590
Storage Capacity 24 Terabytes (24TB)
Interface Type SATA 6Gb/s
Form Factor 3.5-Inch LFF
Recording Technology UltraSMR with OptiNAND
Enclosure Design HelioSeal (Helium-filled)
Performance Metrics
Spindle Rotation Speed 7200 RPM
Data Buffer (Cache) 512 MB
Sustained Transfer Rate Up to 288 MiB/s (Maximum)
Interface Transfer Rate 6.0 Gb/s
Average Latency 4.16 ms

Reliability & Integrity

MTBF (Mean Time Between Failure) 2,500,000 Hours
AFR (Annualized Failure Rate) 0.35%
Workload Rating Up to 550TB per Year
Load/Unload Cycles 600,000

Power & Environmental

Operating Power (Typical) 9.4 Watts
Idle Power (Typical) 5.5 Watts
Operating Temperature 5C to 60C
Non-operating Temperature -40C to 70C
Shock Resistance 40G (2ms, Read/Write)
