VO960JFDGU Technical Specification
HPE 960GB 2.5in SAS-12G Read Intensive G8 G9 G10 SSD
| Manufacturer | HPE |
|---|---|
| Brand | HPE |
General
| Device Type | Solid State Drive – Hot-Swap |
|---|---|
| Capacity | 960 GB |
| NAND Flash Memory Type | Triple-Layer Cell (TLC) |
| Form Factor | 2.5 inch SFF |
| Interface | SAS 12Gbps |
| Plug Type | Hot Pluggable |
| Bytes per Sector | 512 |
| Carrier Type | Smart Carrier |
| Workload Type | Read Intensive |
| Bundled with | HPE Smart Carrier |
Performance
| Endurance DWPD | 1 |
|---|---|
| Drive Transfer Rate | 1.2 GBps (external) |
| MAX Seq. Reads Throughput (MiB/s) | 940 |
| MAX Seq. Writes Throughput (MiB/s) | 900 |
| Random Read IOPS (4KiB, Q=16) | 110000 |
| Random Write IOPS (4KiB, Q=16) | 30000 |
Expansion & Connectivity
| Interfaces | 1 x SAS 12 Gb/s |
|---|---|
| Compatible Bay | 2.5″ SFF |
Power Consumption
| Idle Time | 3.65 Watt |
|---|---|
| Random Read | 4.03 Watt |
| Random Write | 4.03 Watt |
Environmental Parameters
| Min Operating Temperature | 32 °F |
|---|---|
| Max Operating Temperature | 140 °F |
