VO007680JWTBP Technical Specification
HPE 7.68TB SAS 12Gbps Hot Swap Read Intensive 2.5-inch Internal SSD
| Manufacturer | HPE |
|---|---|
| Device Type | Solid State Drive |
| Interface | SAS 12GBPS |
| Plug Type | Hot Pluggable |
| Carrier Type | Smart Carrier (SC) |
| Technical Information of 7.68TB Solid State Drive | |
| Storage Capacity | 7.68 TB |
| NAND Flash Memory Type | Triple-Level Cell (TLC) |
| Connectivity | Dual Port |
| Form Factor | 2.5 inch SFF |
| Workload Type | Read Intensive |
| Features | Digitally Signed Firmware |
| Bundled with | HPE Smart Carrier |
| Platform Supported | HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy |
| Performance | Information for this SAS 12GBPS SSD |
| Lifetime Writes | 14016 |
| Endurance DWPD (Drive Writes Per Day) | 1 |
| Drive Transfer Rate | 12 Gb/sec (external) |
| Random Read IOPS (4KiB, Q=16) | 110000 |
| Max Random Read IOPS (4KiB) | 165000@Q32 |
| Random Write IOPS (4KiB, Q=16) | 48000 |
| Max Random Write IOPS (4KiB) | 48000@Q4 |
| MAX Seq Reads Throughput (MiB/s) | 1075 |
| Max Seq Writes Throughput (MiB/s) | 1030 |
| Random Read Avg. Latency uSec (4KiB,Q1) | 135 |
| Random Write Avg. Latency uSec (4KiB,Q1) | 35 |
| Power Consumption | for 2.5inch Solid State Drive |
| Idle Time | 5.00 Watt |
| Random Read | 6.20 Watt |
| Random Write | 6.20 Watt |
| Sequential Read | 8.56 Watt |
| Sequential Write | 8.56 Watt |
| Random Read/Write | 5.90 Watt |
| Maximum | 8.56 Watt |
Dimensions & Weight
| Height | 5 Inch |
|---|---|
| Width | 7 Inch |
| Depth | 9 Inch |
| Weight | 1.10 Lbs |
