SRX5400X-B2 Juniper Networks SRX 5400 security appliance
SRX5400X-B2 Overview
The SRX5400 Services Gateway is a next-generation security platform ideally suited for service provider, large enterprise and public sector networks. It is based on a revolutionary architecture and utilizes line cards to provide market-leading connectivity, performance and service integration.
$299,145.00
Shipping calculated at checkout.
SRX5400X-B2 Technical Specifications
Juniper Networks SRX 5400 security appliance
| Manufacturer | Netscreen |
|---|---|
| Brand | Juniper, Juniper Networks |
| Product Line | Juniper Networks |
| Model | SRX 5400 |
| Bundled with | Juniper Networks SRX5K-RE-1800X4, SRX5K-SCB3, SRX5K-SPC-4-15-320, SRX5K-MPC3-40G10G |
| Packaged Quantity | :1 |
Chassis
| Built-in Devices | Enhanced midplane |
|---|
Performance
| Performance :IPS throughput | 22 Gbps, Firewall throughput: 65 Gbps, VPN throughput (256-bit AES+SHA1 IPSec): 35 Gbps, Firewall throughput (IMIX): 468 Gbps, Firewall throughput (large packets): 480 Gbps, Latency: 7 µs |
|---|
Capacity
| Capacity :OSPF instances | 400, OSPF routes: 1000000, VPN tunnels (site-to-site): 15000, Maximum number of users: unlimited, BGP peers: 2000, Security zones: 2000, New sessions per second: 420000, Virtual interfaces (VLANs): 4096, BGP routes: 1000000, VPN tunnel interfaces: 15000, Virtual routers: 2000, Maximum logical network members: 32, RIP instances: 50, BGP instances: 1000, Concurrent sessions: 28000000 |
|---|
Networking
| Type | Security appliance |
|---|---|
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Routing Protocol | OSPFv3, OSPF, Bidirectional Forwarding Detection (BFD), RIPng, Static IP routing, Policy-based routing (PBR), RIP-2, IPv4-to-IPv6 Multicast, RIP-1, BGP, ECMP |
| Network / Transport Protocol | DHCP |
| Remote Management Protocol | HTTPS, Telnet, SNMP 3, CLI, SNMP 2, SSH, HTTP |
| Features | Firmware upgradable, DDos attack prevention, Quality of Service (QoS), VPN support, DHCP relay, Weighted Round Robin (WRR) queuing, Syslog support, High Availability, Intrusion Prevention System (IPS), Traffic Control, In-Service Software Upgrade (ISSU), Class of Service (CoS), Traffic shaping, PAT support, DiffServ support, Link Aggregation Control Protocol (LACP), NAT support, Firewall protection, Weighted Random Early Detection (WRED), Fan tray, DHCP server, IPSec Virtual Private Network (VPN), DoS attack prevention, Anti-spyware protection, IPv6 support, Anti-malware protection |
Expansion Slots
| Expansion Slots | :1 (total) / 0 (free) x Switch Control Board (SCB), 2 (total) / 1 (free) x Service Processing Card (SPC), 2 (total) / 1 (free) x expansion slot, 1 (total) / 0 (free) x Routing Engine (RE) |
|---|
Interface Provided
| Interfaces | :6 x 40Gb Ethernet – QSFP+, 24 x 10Gb Ethernet – SFP+ |
|---|
Power Device
| Type | Internal power supply |
|---|---|
| Hot-Plug | Hot-plug |
| Power Redundancy | Optional |
| Installed Qty | :2 |
| Max Supported Qty | :4 |
| Power Provided | :4100 watt |
| Nominal Voltage | AC 120/230 V |
System Requirements
| OS Required | JUNOS |
|---|
Miscellaneous
| Encryption Algorithm | Triple DES, AES, SHA-1, MD5, DES, PKI, DH, IKE |
|---|---|
| Authentication Method | RADIUS |
| Compliant Standards | NEBS level 3, Common Criteria EAL4+, EMC |
Dimensions & Weight
| Width | :17.4 inch |
|---|---|
| Depth | :24.5 inch |
| Height | :8.7 inch |
Environmental Parameters
| Min Operating Temperature | :41 degree Fahrenheit |
|---|---|
| Max Operating Temperature | :104 degree Fahrenheit |
| Humidity Range Operating | :5 – 85% (non-condensing) |
