S+C57DLC10D MikroTik SFP+ Module CWDM, 10Gb/s, 1570nm, 2x LC, 10km, DDM, Single mode
S+C57DLC10D Overview
MikroTik S+C57DLC10D is a single-mode SFP+ module designed for data transmission at a speed of 10 Gbps over a distance of up to 10 km. SFP+ module is equipped with 2 LC output connectors and supports CWDM technology. Transmission takes place through single-mode fibers at 1570 nm wavelength.
$186.00
Shipping calculated at checkout.
S+C57DLC10D Technical Specifications
MikroTik SFP+ Module CWDM, 10Gb/s, 1570nm, 2x LC, 10km, DDM, Single mode
| Manufacture Part Number | S+C57DLC10D |
|---|---|
| Manufacturer | MikroTik |
| Output connector | LC |
| SFP module – port speed | 10 Gbps |
| Transmission distance | 4-20km |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Fiber optic connector | LC |
| Fiber ports quantity | 2 |
| Fiber type | M (Single-Mode) |
| Interface type | SFP+ |
| Maximum data transfer rate | 10000 |
| Maximum transfer distance | 10000 |
| Number of products included | 1 |
| SFP transceiver standard | CWDM |
| SFP transceiver type | Fiber optic |
| Type of SFP duplex | Physical (two fibers) |
| Wavelength | 1570 nm, 1570, |
| Specification | Basic technical parameters |
| Type of module | SFP+ |
| Data transfer rate | 10 Gbps |
| Distance | 10 km |
| Wavelength | 1570 nm |
| Type of transmission | Single-Mode |
| Duplex type | CWDM |
| Output connectors | 2 x LC |
| Operating temperature | 0°C to 70°C |
