QSFP-40G-ESR4 Technical Specifications
Juniper Networks 40GBase QSFP+ Transceiver
40GBASE-ESR Quad Small Form-factor Pluggable Plus (QSFP+).
| Standards | based 40-Gigabit Ethernet (40GBASE-ESR4). |
|---|
40 Gbit/sec line speed.
| Operating | distance up to 400m on OM4 fibre. |
|---|---|
| Transmitter | wavelength 850nm. |
Industry-standard MPO connector.
Multimode Fibre (MMF).
Digital Optical Monitoring (DOM).
| Transmitter | Optical Characteristics |
|---|---|
| Center wavelength [nm] | 850 nm |
| Maximum Tx optical power [dBm] | 0.5 dBm |
| Minimum Tx optical power [dBm] | -7.6 dBm |
| Minimum extinction ratio [dB] | 3.0 dB |
| Receiver | Optical Characteristics |
| Rx sensitivity [dBm] | -11.1 dBm |
| Overload power [dBm] | 2.4 dBm |
