Refurbished QFX5100-48T-DC-AFO Technical Specifications
Juniper QFX5100-48T-DC-AFO Layer 3 Switch
General Information
| Manufacturer |
Juniper Networks, Inc |
| Manufacturer Part Number |
QFX5100-48T-DC-AFO |
| Manufacturer Website Address |
http://www.juniper.net |
| Brand Name |
Juniper |
| Product Series |
QFX5100 |
| Product Model |
QFX5100-48T-DC-AFO |
| Product Name |
QFX5100-48T-DC-AFO Layer 3 Switch |
| Product Type |
Layer 3 Switch |
Technical Information
Interfaces/Ports
| Total Number of Network Ports |
48 |
| Token Ring Port |
No |
| LRE Port |
No |
| Bypass |
No |
| Modular |
No |
| Management Port |
Yes |
| USB |
Yes |
| Number of Network (RJ-45) Ports |
48 |
| Port/Expansion Slot Details |
48 x 10 Gigabit Ethernet Network, 6 x 40 Gigabit Ethernet Expansion Slot |
Media & Performance
| Media Type Supported |
Twisted Pair |
| Ethernet Technology |
10 Gigabit Ethernet, 40 Gigabit Ethernet |
| Network Technology |
10GBase-T, 40GBase-X |
I/O Expansions
| Number of Total Expansion Slots |
6 |
| Expansion Slot Type |
QSFP+ |
Network & Communication
Management & Protocols
| Manageable |
Yes |
| Management |
- Command Line Interface (CLI)
- Web-based Management
- Telnet
- SNMP v1/2/3
- sFlow
- MIB
- VLAN
- DHCP
- QoS
|
Memory
Power Description
| PoE (RJ-45) Port |
No |
| Power Source |
Power Supply |
| Redundant Power Supply Supported |
Yes |
Physical Characteristics
| Compatible Rack Unit |
1U |
| Form Factor |
Rack-mountable |
| Height |
1.7″ |
| Width |
21.5″ |
| Depth |
17.4″ |
| Weight (Approximate) |
24.80 lb |
Miscellaneous
| Package Contents |
- QFX5100-48T-DC-AFO Layer 3 Switch
- 2 x DC Power Supply
|
Certifications & Standards Safety
- CAN/CSA-C22.2 No. 60950-1 (2007) Information Technology Equipment-Safety
- UL 60950-1 (2nd Ed.) Information Technology Equipment-Safety
- EN 60950-1 (2005) Information Technology Equipment-Safety
IEC 60950-1 (2005) Information Technology Equipment-Safety (All country deviations): CB Scheme report.
| EN 60825-1 +A1+A2 (1994) Safety of Laser Products-Part 1 |
Equipment Classifcation |
- GR-63-Core (2006) Network Equipment, Building Systems (NEBS) Physical Protection
- GR-1089-Core (2006) EMC and Electrical Safety for Network Telecommunications Equipment
- SR-3580 (1995) NEBS Criteria Levels (Level 3)
EMC
- FCC 47CFR, Part 15 Class A (2009) USA Radiated Emissions
- EN 55022 Class A (2006)+ A1 2007 European Radiated Emissions
- VCCI Class A (2007) Japanese Radiated Emissions
- BSMI CNS 13438 and NCC C6357 Taiwan Radiated Emissions
- AS/NZS CISPR22:2009
IEEE Standards
- 802.1D
- 802.1w
- 802.1
- 802.1Q
- 802.1p
- 802.1ad
- 802.3ad
- 802.1AB
- 802.3x
- 802.1Qbb
- 802.1Qaz
- 802.1Qau
- 802.1Qbg
| Environmentally Friendly |
Yes |
| Environmental Certification |
RoHS-6, WEEE, REACH, 80 Plus Silver, China RoHS |
