NS-ISG-1000 Technical Specifications
Juniper Networks ISG 1000 Advanced security appliance
| Manufacturer | Netscreen |
|---|---|
| Brand | Juniper, Juniper Networks |
| Product Line | Juniper Networks NetScreen |
| Model | ISG 1000 Advanced |
| Packaged Quantity | :1 |
Optical Storage
| Type | None |
|---|
Card Reader
| Supported Flash Memory Cards | CompactFlash Card |
|---|
Performance
| Performance :3DES throughput | 1 Gbps, Firewall throughput: 1 Gbps |
|---|
Capacity
| Capacity :Security policies | 10000, Connection / user qty: 5000, Concurrent sessions: 250000, VPN tunnels: 2000 |
|---|
Networking
| Type | Security appliance |
|---|---|
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Routing Protocol | RIP-2, BGP, Static IP routing, OSPF |
| Network / Transport Protocol | L2TP, IPSec, PPPoE |
| Remote Management Protocol | SNMP, SNMP 2, HTTP, HTTPS |
| Features | Intrusion Detection System (IDS), DiffServ support, Routing, DHCP support, DoS attack prevention, URL filtering, Firewall protection, LDAP support, Syslog support, VPN support, Deep Packet Inspection (DPI), High Availability, PAT support, Intrusion Prevention System (IPS), VLAN support, NAT support, Transparency |
| IP | Telephony |
| VoIP | Yes |
| VoIP Protocols | SIP, SCCP, MGCP, H.323 |
Expansion Slots
| Expansion Slots | :2 (total) / 2 (free) x expansion slot |
|---|
Interface Provided
| Interfaces | :4 x 1000Base-T – RJ-45, 1 x management |
|---|---|
| OS | Provided |
| Type | ScreenOS |
Power Device
| Type | Internal power supply |
|---|---|
| Power Provided | :250 watt |
| Nominal Voltage | AC 120/230 V |
Miscellaneous
| Encryption Algorithm | AES, SHA-1, IKE, Triple DES, RSA, DES, MD5 |
|---|---|
| Authentication Method | LDAP, RADIUS, Secure Shell v.2 (SSH2), X.509 certificates |
| Compliant Standards | VCCI Class A ITE, BSMI, CSA, UL, CB, cUL, FCC Class B certified, C-Tick |
Dimensions & Weight
| Width | :17.5 inch |
|---|---|
| Depth | :17.2 inch |
| Height | :5.2 inch |
| Weight | :29.98 lbs |
Environmental Parameters
| Min Operating Temperature | :32 degree Fahrenheit |
|---|---|
| Max Operating Temperature | :122 degree Fahrenheit |
| Humidity Range Operating | :10 – 90% |
