LBH2001A-H-SC Black Box Hardened Media Converter Switch 120-240-VAC Fiber Media Convert
LBH2001A-H-SC Overview
Switch at Gigabit speeds between copper and multimode fiber in industrial areas at distances of up to 550 meters on 50-µm fiber or 220 meters on 62.5-µm. Switch traffic between a Gigabit-speed fiber multimode backbone and two copper Gigabit segments. Or use the second copper port to provide access to other Ethernet devices. Supports distances up to 550 meters (1804.4 ft.) on 50-um fiber or 220 meters (721.8 ft.) on 62.5-um fiber.? Features high-grade components and special thermal design for industrial use. Robust steel case protects circuitry and communications from the demands of factory applications.
$473.00
Shipping calculated at checkout.
LBH2001A-H-SC Technical Specifications
Black Box Hardened Media Converter Switch 120-240-VAC Fiber Media Convert
| Brand | Black Box |
|---|---|
| Manufacture Part Number | LBH2001A-H-SC |
| Product Line | Black Box Hardened Media Converter Switch |
| Model | 120-240-VAC |
| Manufacturer | Black Box |
Network & Communication
| Connectivity Technology | Wired |
|---|---|
| Data Link Protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate | 1 GBps |
| Features | Full duplex capability, Switching |
| Form Factor | External |
| MAC Address Table Size | 1K entries |
| Max Transfer Distance | 1800 ft |
| Optical Wave Length | 850 nm |
| Product Type | Fiber media converter |
| Status Indicators | Link OK, Receive |
Cables
| Left Connector SD Type | RJ-45 |
|---|---|
| Right Connector Type (SD) | SC multi-mode |
Technical Information
| Operating Humidity | 5 – 95% |
|---|
Product Information
| Device Type | Internal power supply |
|---|---|
| Packaged Quantity | 1 |
Dimensions & Weight
| Height | 3.5 inch |
|---|---|
| Weight | 3.53 ounce |
| Width | 3 inch |
| Depth | 1 inch |
