IC6500FIPS Technical Specifications
Juniper Networks Enterprise Infranet Controller 6500 FIPS Base System
| Manufacturer | Netscreen |
|---|---|
| Brand | Juniper, Juniper Networks |
| Product Line | Juniper Networks Enterprise Infranet Controller |
| Model | :6500 FIPS Base System |
| Packaged Quantity | :1 |
Optical Storage
| Type | None |
|---|
Networking
| Type | Security appliance |
|---|---|
| Form Factor | External |
| Ports Qty | :4 |
| Connectivity Technology | Wired |
| Data Link Protocol | Fast Ethernet, Ethernet, Gigabit Ethernet |
| Data Transfer Rate | :1 GBps |
| Status Indicators | Power, Alert, HDD activity, Fail |
| Compliant Standards | IEEE 802.3z, IEEE 802.3u, IEEE 802.3ab |
Interface Provided
| Interfaces | :4 x 1000Base-T – RJ-45, 1 x management – RJ-45 |
|---|
Power Device
| Type | Internal power supply |
|---|---|
| Hot-Plug | Hot-plug |
| Max Supported Qty | :2 |
| Nominal Voltage | AC 120/230 V |
| Frequency Required | :50/60 hertz |
Miscellaneous
| Height (Rack Units) | :2 |
|---|---|
| Compliant Standards | UL 60950-1, VCCI Class A ITE, FCC Class A certified, EN 60950-1, EN 61000-3-2, EN55022 Class A, CSA C22.2 No. 60950-1-03, IEC 60950-1, EN55024 |
Dimensions & Weight
| Width | :17.2 inch |
|---|---|
| Depth | :17.7 inch |
| Height | :3.5 inch |
| Weight | :26.9 lbs |
Environmental Parameters
| Min Operating Temperature | :41 degree Fahrenheit |
|---|---|
| Max Operating Temperature | :104 degree Fahrenheit |
| Humidity Range Operating | :8 – 90% (non-condensing) |
