HAT5300-8T Synology HAT5300 Hard Drive 8TB SATA 6Gb/s
HAT5300-8T Overview
Synology HAT5300 Hard Drive 8TB SATA 6Gb/s
$470.00
Shipping calculated at checkout.
HAT5300-8T Technical Specifications
Synology HAT5300 Hard Drive 8TB SATA 6Gb/s
| Brand | Synology |
|---|---|
| Product Line | Synology |
| Model | HAT5300 |
| Manufacturer | Synology |
Storage
| Buffer Size | 256 megabyte |
|---|---|
| Bytes per Sector | 512 |
| Data Transfer Rate | (Hard Drive) 600 MBps |
| Form Factor (Short) | 3.5″ |
| Form Factor (Short) (metric) | 8.9 cm |
| Hard Drive Capacity | 8 TB |
| Hard Drive | Features |
| Workload | up to 550 TB per year |
| Hard Drive | Type |
| Internal | hard drive |
| HD Interface |
|
| Max | Internal Data Transfer Rate |
| 230 MBps | |
| Spindle Speed | (rpm) |
| 7200 revolutions per minute | |
| Storage | Interface |
- Serial ATA-600
- 24×7 Operation
- Yes
Power
| Power Consumption | 6.38 Watt (idle), 9.1 Watt (random read/write) |
|---|
Technical Information
| Compatible Bay | 3.5″ |
|---|---|
| Hard Drive Form Factor | 3.5″ |
| Hard Drive Form Factor | (metric) 8.9 cm |
| Max Operating Temperature | 60 degree Celsius |
| Max Storage Temperature | 70 degree Celsius |
| Min Operating Temperature | 5 degree Celsius |
Min Storage Temperature -40 degree Celsius
| Mtbf | 2,500,000 Hours |
|---|---|
| Operating Humidity | 5 – 90% (non-condensing) |
| Shock | Acceleration (Non-operating) 250 gram |
| Shock | Acceleration (Operating) 70 gram |
| Shock | Duration (Non-operating) 2 ms |
| Shock | Duration (Operating) 2 ms |
| Vibration | Acceleration (Non-operating) 3 gram |
| Vibration | Acceleration (Operating) 0.75 gram |
| Vibration | Frequency Range (Non-operating) 5-500 Hz |
| Vibration | Frequency Range (Operating) 5-300 Hz |
Product Information
| Packaged Quantity | 1 |
|---|---|
| Product Type | Hard drive |
Dimensions & Weight
| Height | 26.1 millimetre |
|---|---|
| Weight | 770 gram |
| Width | 101.85 millimetre |
| Depth | 147 millimetre |
