FTLX6624MCC Finisar TX/RX Optical Fiber 11.35Gbps 30-Pin XFP
FTLX6624MCC Overview
-xx Small Form Factor 10Gb/s (XFP) transceiver complies with the XFP Multi-Source Agreement (MSA) Specification. It supports amplified DWDM 10Gb/s SONET/SDH, 10 Gigabit Ethernet, and 10 Gigabit Fibre Channel applications over 40km of fiber without dispersion compensation
$1,405.00
Shipping calculated at checkout.
FTLX6624MCC Technical Specifications
TX/RX Optical Fiber 11.35Gbps 30-Pin XFP
| Data Rate | 11.35 Gbps 10 Gigabit Ethernet |
|---|
Family FTLX6624MCC
| Maximum | Fall Time 0.04 ns |
|---|---|
| Mounting | Snap Fit To Panel Mount |
| Operating Supply Voltage | 3.1300, 3.4600, 4.7500, 5.2500 V |
Operating Temperature -5 to 70 °C
| Pin Count | 30 |
|---|---|
| Product Dimensions | 78 x 18.35 x 8.5 mm |
Screening Level Commercial
| Type | TX/RX |
|---|---|
| Typical Rise Time 0.04 ns | |
| Fiber Mode |
|
| Fiber Type | describes the mode of operation if it single mode or multimode. |
| Peak Wavelength | (nm) |
| 1563.86(Max)/1615(Max) | |
| Form | Factor |
| XFP | |
