FTLQ8181EBNM Finisar Transceiver Module
FTLQ8181EBNM Overview
Fibre Optic Transmitters, Receivers, Transceivers 4x10G Parallel VCSEL, 4x10G PIN, 40GBASE-SR4 100m 40GbE, 41.2Gb/s, RoHS, multimode, CFP, flat top, 3.3V, 6W, MPO receptacle, -0/70 C operation, 100m on OM3, 150m on OM4
$2,355.00
Shipping calculated at checkout.
FTLQ8181EBNM Technical Specifications
Transceiver Module
| Manufacturer | Finisar |
|---|---|
| Product Category | Fibre Optic Transmitters, Receivers, Transceivers |
| Product | Transceivers |
| Wavelength | 850 nm |
| Data Rate | 41.2 Gb/s 40 Gigabit Ethernet |
| Fibre Type | Multi mode Fibre (MMF) |
| Form Factor or Case Style | CFP |
| Emitting Source | VCSEL |
| Operating Supply Voltage | 3.3 V |
| Minimum Operating Temperature | 0 C |
| Maximum Operating Temperature | + 70 C |
| Application | Ethernet |
| Connector Type | MTP (MPO) |
| Package/Case | – |
| Brand | Finisar |
| Mounting Style | Pluggable |
| Product Type | Fiber Optic Transmitters, Receivers, Transceivers |
