FIM-7904E Fortinet Interface Module Expansion module
FIM-7904E Overview
Fortinet Interface Module Expansion module. This Fortinet Interface Module provides data, management and session sync/heartbeat interfaces, base backplane switching and fabric backplane session-aware load balancing for a FortiGate-7000 series chassis. It includes an integrated switch fabric and DP2 processors to load balance millions of data sessions over the chassis fabric backplane to FPM processor modules.
$37,849.00
Shipping calculated at checkout.
FIM-7904E Technical Specifications
Fortinet Interface Module Expansion module
| Manufacturer | Fortinet |
|---|---|
| Brand | Fortinet |
| Product Line | Fortinet Interface Module |
| Packaged Quantity | 1 |
Networking
| Type | Expansion module |
|---|---|
| Form Factor | Plug-in module |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet, 40 Gigabit Ethernet |
| Data Transfer Rate | 40 GBps |
Ports
| Qty | 8 |
|---|---|
| Type | 40 Gigabit QSFP+ |
Interface Provided
| Interfaces | 1 x USB 3.0 – 9 pin USB Type A, 2 x 10Gb Ethernet – SFP+, 4 x 1000Base-T (management) – RJ-45, 8 x 40Gb Ethernet – QSFP+ |
|---|
Miscellaneous
| Color Category | Silver |
|---|---|
| Included Accessories | 2 x SFP+ SR transceivers |
Dimensions & Weight
| Width | 11.3 inch |
|---|---|
| Depth | 13.8 inch |
| Height | 1.2 inch |
| Weight | 7.12 lbs |
Environmental Parameters
| Min Operating Temperature | 32 degree Fahrenheit |
|---|---|
| Max Operating Temperature | 104 degree Fahrenheit |
| Humidity Range Operating | 10 – 90% (non-condensing) |
