| Type |
Switch |
| Subcategory |
Network hubs and switches |
| Subtype |
Gigabit Ethernet |
| Form Factor |
Rack-mountable |
| Stackable |
Stackable |
| Max Units In A Stack |
10 |
| Ports Qty |
24 |
| Advanced Switching |
Layer 3 |
| Routing Protocol |
Bidirectional Forwarding Detection (BFD), IGMP, BGP, IGMPv2, Static IPv4 routing, RIPng, CIDR, VRRP, PIM-SSM, OSPF, RIP-2, RIP-1, IS-IS, OSPFv3, VRRPv3, Static IPv6 routing, MPLS, PIM-DM, PIM-SM, IGMPv3 |
| MAC Address Table Size |
64K entries |
| Jumbo Frame Support |
9216 bytes |
| Manageable |
Yes |
| Remote Management Protocol |
RMON 3, RMON 9, SNMP 2, HTTPS, RMON 2, Telnet, HTTP, CLI, SNMP 3, RMON 1, SSH-2, SSH, SNMP 1 |
| Status Indicators |
LCD display |
| Features |
DHCP snooping, Time Domain Reflectometry (TDR), VLAN support, MLD snooping, BOOTP support, Deficit Weighted Round Robin (DWRR), Rapid Spanning Tree Protocol (RSTP) support, Store and forward, Hot swappable dual fans, DHCP relay, sFlow, DoS attack prevention, Link Aggregation Control Protocol (LACP), VLAN Spanning Tree Protocol (VSTP), DiffServ support, SNTP support, LLDP support, Virtual Chassis technology, DHCP client, DHCP proxy, Dynamic ARP Inspection (DAI), NTP time synchronization, Per-VLAN Spanning Tree Plus (PVST+), Neighbor Discovery Protocol (NDP), ARP support, RARP support, Temperature sensor, IPv6 support, Graceful Route Engine Switchover (GRES), Multiple Spanning Tree Protocol (MSTP) support, Strict Priority (SP), Management Information Base (MIB), Multicast Source Discovery Protocol (MSDP), Spanning Tree Protocol (STP) support, Captive Portal, Auto-uplink (auto MDI/MDI-X), DHCP server, High Availability, Front to back airflow, Redundant trunk group (RTG), Energy Efficient Ethernet, Quality of Service (QoS), Access Control List (ACL) support, Tagged VLAN, DDos attack prevention, ASIC VPN, Trivial File Transfer Protocol (TFTP) support, Class of Service (CoS), Redundant hot swappable fans, Virtual Routing and Forwarding (VRF), Weighted Random Early Detection (WRED), Flow control, IGMP snooping, IPv4 support |
| Compliant Standards |
IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ae, IEEE 802.3, IEEE 802.1ae, IEEE 802.3ah, IEEE 802.3z, IEEE 802.1Q, IEEE 802.1ak, IEEE 802.3ba, IEEE 802.1w, IEEE 802.1D, IEEE 802.3ad (LACP), ITU-T G.8032, IEEE 802.1x, IEEE 802.1s, IEEE 802.3x, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.3u |
