CWDM-SFP-1470 Technical Specifications
Cisco CWDM 1470nm SFP Gigabit Ethernet and 1G/2G FC Transceiver Module.
General Information
| Manufacturer | Cisco Systems, Inc |
|---|---|
| Manufacturer Part Number | CWDM-SFP-1470 |
| Brand Name | Cisco |
| Product Name | CWDM 1470-nm SFP |
| Product Type | SFP |
Technical Information
| Application/Usage | Data Networking |
|---|
Interfaces/Ports
| Interfaces/Ports | 1 x 1000Base-X |
|---|---|
| Interfaces/Ports Details | 1 x LC Duplex 1000BASE-CWDM |
Media & Performance
| Connectivity Media | Optical Fiber 1000Base-X |
|---|---|
| Data Transfer Rate | 2.12 Gbps Fibre Channel Full-duplex |
| Data Transfer Rate | 1.25 Gbps Gigabit Ethernet Full-duplex |
Miscellaneous
| Additional Information |
|
|---|---|
| Center wavelength | is 1470nm |
| Color | Gray |
| Compliant with the ITU-T G.694.2 CWDM grid | |
| Compatible with | Fibre Channel Draft Physical Interface Specification (FC-PI 10.0) |
| Fibre Channel | 1.06 and 2.12 Gbps full-duplex links with an optical link budget of 28 dB |
| Compatibility- | Catalyst 2900 series, Catalyst 2950 series, Catalyst 2960 series, Catalyst 3560 series |
