C9500-48X-A Technical Specifications
Catalyst 9500 48-port 10G bundle, Network Advantage
Capacity
| Type | FNF entries |
|---|---|
| Value | :512000 |
| Type | Host IPv4 routes |
| Value | :32000 |
| Type | Host IPv6 routes |
| Value | :16000 |
| Type | Indirect IPv4 routes |
| Value | :64000 |
| Type | Indirect IPv6 routes |
| Type | Multicast scale |
| Value | :48000 |
| Type | QoS ACL scale |
| Value | :18000 |
| Type | Security ACL scale |
| Type | Switched virtual interfaces (SVIs) |
| Type | VLAN IDs |
| Value | :4000 |
Dimensions & Weight
| Depth | :21.5 in |
|---|---|
| Height | :1.7 in |
| Weight | :25.75 lbs |
| Width | :17.5 in |
Environmental Parameters
| Humidity Range Operating | :5 – 90% (non-condensing) |
|---|---|
| Humidity Range Storage | :5 – 95% (non-condensing) |
| Max Operating Temperature | :104 °F |
| Max Storage Temperature | :149 °F |
| Min Operating Temperature | :32 °F |
| Min Storage Temperature | -4 °F |
