C9300L-24UXG2Q-1A Technical Specifications
Cisco Catalyst 9300L Network Advantage Switch 24 ports Managed Rack-mountable
| Device Type | Switch – 24 ports – L3 – managed – stackable |
|---|---|
| Bundled Services | 10 years Network Advantage |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Power Over Ethernet (PoE) | UPOE |
| PoE Budget | 722 W |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 198 bytes |
| Encryption Algorithm | 128-bit AES, 256-bit AES |
| RAM | 8 GB |
| Flash Memory | 16 GB |
| Status Indicators | Status |
Expansion / Connectivity
Power
| Power Device | Internal power supply – hot-plug |
|---|---|
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 1100 Watt |
| Voltage Required | AC 100-240 V (50 – 60 Hz) |
Miscellaneous
| Mtbf | 291,670 hours |
|---|
Dimensions & Weight
| Width | 17.5 in |
|---|---|
| Depth | 1.7 in |
| Height | 19.2 in |
| Weight | 16.01 lbs |
