C9200L-24PXG-4X-1E Technical Specifications
Cisco Systems C9200L 24 Port PoE+ Network Essentials 1Y
| Manufacturer Part Number | C9200L-24PXG-4X-1E |
|---|---|
| Product Type | Ethernet Switch |
| Manageable | Yes |
| Ethernet Technology | Gigabit Ethernet, 10 Gigabit Ethernet |
| Product Family | Catalyst 9200 |
| Stack Port | Yes |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 24 |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
| Energy Star | Yes |
| Form Factor | Rack-mountable |
| Power Consumption | 600 W |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Environmentally Friendly | Yes |
| Uplink Port | Yes |
| Port / Expansion Slot Details | 8 x 10 Gigabit Ethernet PoE+, 16 x Gigabit Ethernet PoE+, 4 x 10 Gigabit Ethernet Uplink |
| PoE Budget | 370 W |
| Country of Origin | Mexico |
| Height | 1.7″ |
| Width | 17.5″ |
| Depth | 13.8″ |
| Product Series | 9200 |
| Product Model | C9200L-24PXG-4X |
| Network Technology | 1000Base-T, 10GBase-T |
| Product Line | Catalyst |
