C9200-48P-EDU Technical Specifications
Cisco Catalyst 9200 Switch 48 Port Managed Rack Mountable
Capacity
| Type | Flexible NetFlow entries |
|---|---|
| Value | 16000 |
| Type | IPv4 routing table entries |
| Value | 4000 |
| Type | IPv6 routing table entries |
| Value | 2000 |
| Type | Packet buffer size |
| Value | 6 MB |
| Type | Switched virtual interfaces (SVIs) |
| Value | 1000 |
| Type | Virtual networks |
| Value | 4 |
| Type | VLAN IDs |
| Value | 4096 |
Dimensions & Weight
| Depth | 13.8 in |
|---|---|
| Height | 1.7 in |
| Weight | 12.13 lbs |
| Width | 17.5 in |
Environmental Parameters
| Humidity Range Operating | 5 – 90% (non-condensing) |
|---|---|
| Humidity Range Storage | 5 – 90% (non-condensing) |
| Max Operating Temperature | 113 °F |
| Max Storage Temperature | 158 °F |
| Min Operating Temperature | 23 °F |
| Min Storage Temperature | -40 °F |
Flash Memory
| Installed Size | 4 GB |
|---|
| Brand | Cisco |
|---|---|
| Manufacturer | CISCO DS HARDWARE DIRECT |
| Model | 9200 |
| Packaged Quantity | 1 |
| Product Line | Cisco Catalyst |
