AIR-AP1572EAC-E-K9 Technical Specification
Cisco Aironet wireless access point
| Manufacturer | CISCO DS HARDWARE DIRECT |
|---|---|
| Brand | Cisco |
| Product Line | Cisco Aironet |
| Model | :1572EAC |
| Packaged Quantity | :1 |
Chassis
| Ruggedized Design | Outdoor |
|---|---|
| Built-in Devices | GPS |
Line Properties
| Line Coding Format | CCK |
|---|
Networking
| Type | Wireless access point |
|---|---|
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wireless Protocol | :802.11a/b/g/n/ac |
| Network / Transport Protocol | IPSec, L2TP |
| Remote Management Protocol | CLI, HTTP |
| Data Transfer Rate | :1.3 GBps |
Wi-Fi Bands :2.4 GHz, 5 GHz
| Spread Spectrum Method | DSSS |
|---|---|
| Power Over Ethernet (PoE) | UPOE |
| Status Indicators | Status |
| Features | :4T4R MIMO technology, Auto-sensing per device, Beamforming technology, Cisco Flexible Antenna Port technology, CleanAir 2.0 technology, ClientLink 3.0 technology, Cyclic shift diversity (CSD), DFS support, GPS sync compatible, MAC address filtering, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Pole mountable, Reset button, VPN passthrough |
| Compliant Standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at, Wi-Fi CERTIFIED |
Interface Provided
| Interfaces | :1 x – SFP (mini-GBIC), 1 x 1000Base-T (PoE+) – RJ-45, 1 x antenna, 1 x console – RJ-45, 4 x antenna – N connector |
|---|
Power Device
| Nominal Voltage | AC 120/230 V / DC 10 – 16 V |
|---|---|
| Frequency Required | :50/60 hertz |
Miscellaneous
| Encryption Algorithm | AES, LEAP, PEAP, TKIP, TLS, TTLS, WPA, WPA2 |
|---|---|
| Authentication Method | Extensible Authentication Protocol (EAP), X.509 certificates |
| Compliant Standards | ANSI C62.41, ARIB STD-T66, ARIB STD-T71, AS/NZS 4268, EN 300 328, EN 300.328, EN 301 489-1, EN 301 489-17, EN 301 893, EN 301.489.1, EN 301.489.17, EN 301.893, EN 60950-1 Second Edition, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, FCC Part 15.107, FCC Part 15.109, FCC Part 15.247, FCC Part 15.407, ICES-003, IEC 60950-1 Second Edition, IP67, NEMA Type 4X, OET 65 C, RSS-102, RSS-210, UL 60950-1 Second Edition |
Dimensions & Weight
| Width | :7.9 inch |
|---|---|
| Depth | :6.3 inch |
| Height | :11.8 inch |
| Weight | :13.45 lbs |
