Refurbished A900-IMA8D Cisco ASR 900 8-Port T1/E1 expansion module
Refurbished A900-IMA8D Overview
Cisco ASR 900 series Ethernet interface modules are designed to give customers a high degree of flexibility and value. All Ethernet interface modules share a common core that supports time stamping on the module for Y.1731 operations, administration, and maintenance (OAM) delay measurement functions to achieve precise results for one-way and two-way delay measurement. The modules also provide time-stamping functions for the IEEE 1588-2008 protocol. These time stamps help ensure that ASR 900 series routers achieve outstanding results when deploying IEEE 1588-2008 protocols for frequency and phase synchronization. Not all customers will deploy IEEE 1588-2008 for synchronization. Therefore, the Ethernet interface modules also support input and output frequency synchronization using synchronous Ethernet (SyncE).
$1,099.00
Refurbished A900-IMA8D Technical Specification
Cisco ASR 900 8-Port T1/E1 expansion module
| Manufacturer | CISCO DS HARDWARE DIRECT |
|---|---|
| Brand | Cisco |
| Product Line | Cisco ASR 900 |
| Model | :8-Port T1/E1 Interface Module |
| Packaged Quantity | :1 |
Line Properties
| Line Rate | T-1/E-1 |
|---|
Networking
| Type | Expansion module |
|---|---|
| Form Factor | Plug-in module |
| Connectivity Technology | Wired |
| Compliant Standards | G.703, G.704, ITU-T G.824 |
Interface Provided
| Interfaces | :8 x T1/E1 |
|---|
Slot Required
| Compatible Slots | :1 x expansion slot |
|---|
Power Device
| Power Consumption Operational | :14 watt |
|---|
Miscellaneous
| Mtbf | :700,000 hour(s) |
|---|
Compatibility
| Compatible With :P/N | A900-RSP2A-128, A900-RSP2A-128=, A900-RSP2A-128-RF, A900-RSP2A-128-WS, A900-RSP2A-64, A900-RSP2A-64=, A900-RSP2A-64-RF, A900-RSP2A-64-WS |
|---|
