7613-RSP720CXL-P Technical Specifications
Cisco 7613 Chassis,13-slot,RSP720-3CXL,PS
| Manufacturer | Cisco |
|---|---|
| Manufacturer Part Number | 7613-RSP720CXL-P |
| Capacity:IPv4 routes | 1000000 ¦ IPv6 routes: 500000 ¦ NetFlow entries: 256000 ¦ ACL rules: 256000 |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Device Type | Router |
| Enclosure Type | Plug-in module – modular – 18U |
| Network / Transport Protocol | TCP/IP, ICMP/IP |
| Performance | IPv4 routing: 400 Mbps |
| Processor | PowerPC 1.2 GHz |
| RAM | 3 GB (installed) / 6 GB (max) |
| Routing Protocol | OSPF, RIP, BGP-4, IS-IS, IGMP, PIM-SM, PIM-DM |
Miscellaneous
| Rack Mounting Kit | Included |
|---|
Power
| Installed Qty | 1 (installed) / 2 (max) |
|---|---|
| Power Device | Internal power supply – hot-plug |
| Power Redundancy | Yes |
Dimensions & Weight
| Depth | 44.7 cm |
|---|---|
| Height | 82.3 cm |
| Width | 42.5 cm |
Environmental Parameters
| Humidity Range Operating | 10 – 85% |
|---|---|
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
