| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Performance IPv4 routing |
400 Mbps ¦ IPv6 routing: 200 Mbps ¦ Switching capacity: 720 Gbps |
| Capacity IPv4 routes |
256000 ¦ IPv6 routes: 128000 ¦ NetFlow entries: 128000 ¦ ACL rules: 128000 |
| Network / Transport Protocol |
TCP/IP, ICMP/IP, DHCP |
| Routing Protocol |
OSPF, RIP, BGP-4, IS-IS, IGMP, PIM-SM, PIM-DM, GRE, Bidirectional PIM |
| Features |
Layer 3 switching, layer 2 switching, DHCP support, MPLS support, VLAN support, IGMP snooping, DoS attack prevention, Access Control List (ACL) support, Quality of Service (QoS), MPLS VPN, Virtual Route Forwarding-Lite (VRF-Lite) |
| Compliant Standards |
IEEE 802.1x, NEBS level 3, ETSI, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, AS/NZS 3260, AS/NZ 3548 Class A, CSA C22.2 No. 60950-00, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, FCC CFR21 Part 1040, IEC 60825-1, EN 60825-1 |
| RAM |
2 GB (installed) / 6 GB (max) |
| Flash Memory |
1 GB (installed) / 2 GB (max) |
