1000-16I Technical Specifications
Adaptec 12 Gigabyte(GB) 16 Ports Peripheral Component Interconnect Express (PCIE) 3.0 X8 Serial-Attached SCSI (SAS) Serial Advanced Technology Attachment (SATA) Host Bus Adapter (HBA)
| Manufacturer | Adaptec |
|---|---|
| Model Number or SKU# | 1000-16I |
| Product Name | Controller |
| Product Type | Host Bus Adapter |
| Interface | PCI Express 3.0 x8 |
| Port count | 16 ports |
| Data transfer rate | Up to 12 Gbps per port |
| Supported protocols | SAS, SATA |
| RAID support | RAID 0, 1, 10, 5, 50, 6, 60 |
| Maximum number of devices supported | 256 |
| Operating system compatibility | Windows, Linux, VMware, and Solaris |
| Bus mastering | Yes |
| Command queuing | Yes |
| RoHS compliant | Yes |
| Form factor | Low-profile, half-length |
| Power consumption | 22W |
| Operating temperature | 0°C to 55°C |
| Operating humidity | 20% to 80% non-condensing |
| Dimensions | 6.6 x 2.5 inches |
| Weight | 0.5 pounds |
