01CV843 Lenovo Emulex 16GB (GEN 6) FC Dual-Ports Host Bus
01CV843 Overview
The Lenovo Emulex 16GB (GEN 6) FC Dual-Ports Host Bus Adapter provides high levels of performance and reliability, making it an ideal storage solution for businesses and organizations
High-speed connectivity: The HBA features 16GB of fiber channel connectivity, providing fast and efficient data transfers. This helps to improve the overall performance of the storage solution.
$750.00
Shipping calculated at checkout.
01CV843 Technical Specifications
Lenovo Emulex 16GB (GEN 6) FC Dual-Ports Host Bus
| Brand | Lenovo |
|---|---|
| Type | Controller |
| Sub-Type | Fibre Channel |
Technical Information
| I/O Controller | Emulex Engine 501 (Xe501) I/O Controller (Ioc) |
|---|---|
| Host Interface | PCIE 3.0×8 |
| Port | Single-Port And Dual-Port Sfp+ Based Adapters |
| Link Speed | Support For 16GB,8GB And 4GB Fc Link Speeds,M Which Are Automatically Negotiated. |
| Data Rate | 14.025 GBps(1600 MBps), 8.5 GBps(800 MBps), And 4.25 GBps (400 Mbps) Autosensing (Per Port), With Full Duplex. |
| Performance | Up To 1,600,000 Lops. |
| Topology | Point-To-Point And Switched Fabric. |
