X-320-0008-R5-C Technical Specifications
Brocade 300 Switch 8 Ports Rack-Mountable
Rack Mounting Kit: Optional
Compliant Standards: RoHS
Dimensions & Weight
Width: 16.9 in
Depth: 12.1 in
Height: 1.7 in
Weight: 9.26 lbs
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 10 – 85%
General
Device Type: Switch – 8 ports
Enclosure Type: Rack-mountable 1U
Subtype: Fibre Channel
Ports: 8 x 4Gb Fibre Channel
Remote Management Protocol: SNMP 1, Telnet, SNMP 3, HTTP, HTTPS
Encryption Algorithm: SSL
Authentication Method: RADIUS, Secure Shell v.2 (SSH2), LDAP, DH-CHAP
Expansion / Connectivity
Installed Modules Qty (Max): 8 (installed) / 24 (max)
Power
Power Device: Internal power supply
Voltage Required: AC 120/230 V (50/60 Hz)
Power Consumption Operational: 57 Watt
