WS C246 PRO Technical Specifications
ASUS Workstation MB LGA1151 ECC DDR4 M.2 C246 SV WS
General Information
Product Name WS C246 Pro Workstation MB LGA1151 ECC DDR4 M.2 C246 SV WS
Product Model WS C246 PRO
Product Type Workstation Motherboard
Audio
Audio Channels 7.1
Interfaces/Ports
Total Number of USB Ports 6
Number of USB 3.0 Ports 4
Number of USB 3.1 Ports 2
VGA Yes
HDMI Yes
DisplayPort Yes
DVI Yes
I/O Expansions
Number of Total Expansion Slots 6
Total Number of PCI Express Slots 6
Number of PCI Express x1 Slots 2
Number of PCI Express x16 Slots 4
Memory
Number of Memory Slots 4
Memory Form Factor UDIMM
DIMM
Maximum Memory 64 GB
Memory Speed Supported 2666 MHz
2400 MHz
2133 MHz
Memory Technology DDR4 SDRAM
Intel Optane Memory Ready Yes
Network & Communication
Gigabit Ethernet Yes
Processor & Chipset
Chipset Manufacturer Intel
Total Processor Supported 1
Processor Socket Socket H4 LGA-1151
Processor Supported Xeon
Pentium
Celeron
Core i3
Core i5
Core i7
