WDS200T2B0C Technical Specifications
WD Blue SN550 NVMe SSD solid state drive 2TB PCI Express
Manufacturer :Western Digital
Brand :WD
Product Line :WD Blue SN550 NVMe SSD
Model :WDS200T2B0C
Packaged Quantity :1
Storage
Type :Solid state drive
Hard Drive
Hard Drive Type :Internal hard drive
Form Factor :M.2 2280
Form Factor (metric) :M.2 2280
Form Factor (Short) :M.2
Form Factor (Short) (metric) :M.2
Storage Interface :PCI Express 3.0 x4 (NVMe)
Interface :PCI Express 3.0 x4 (NVMe)
Capacity :2 TB
Internal Data Rate :2600 MBps
Internal Data Rate (Write) :1800 MBps
4KB Random Read :360000 IOPS
4KB Random Write :384000 IOPS
SSD Endurance :900 TB
Features :3D NAND Technology
Interface Provided
Interfaces :1 x PCI Express 3.0 x4 (NVMe) – M.2 Card
Bay Required
Compatible Bay :M.2 2280
Power Consumption
Power Consumption :3.9 Watt (maximum), 30 mW (low power active), 5 mW (sleep)
Miscellaneous
MTBF :1,700,000 Hours
Compliant Standards :BSMI, CAD ICES-3(B)/NMB3(B), FCC, KCC, Morocco, RCM, TUV, UL, VCCI
Dimensions & Weight
Width :0.9 inch
Depth :3.1 inch
Height :0.1 inch
Weight :0.23 ounce
