Refurbished VO007680JWTBP-RF Technical Specifications
HPE 7.68TB SAS 12Gbps Hot Swap Read 2.5-inch
Manufacturer: HPE
Device Type: Solid State Drive
Interface: SAS 12GBPS
Plug Type: Hot Pluggable
Carrier Type: Smart Carrier (SC)
Technical Information of 7.68TB Solid State Drive
Storage Capacity: 7.68 TB
NAND Flash Memory Type: Triple-Level Cell (TLC)
Connectivity: Dual Port
Form Factor: 2.5 inch SFF
Workload Type: Read Intensive
Features: Digitally Signed Firmware
Bundled with: HPE Smart Carrier
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Performance Information for this SAS 12GBPS SSD
Lifetime Writes: 14016
Endurance DWPD (Drive Writes Per Day): 1
Drive Transfer Rate: 12 Gb/sec (external)
Random Read IOPS (4KiB, Q=16): 110000
Max Random Read IOPS (4KiB): 165000@Q32
Random Write IOPS (4KiB, Q=16): 48000
Max Random Write IOPS (4KiB): 48000@Q4
MAX Seq Reads Throughput (MiB/s): 1075
Max Seq Writes Throughput (MiB/s): 1030
Random Read Avg. Latency uSec (4KiB,Q1): 135
Random Write Avg. Latency uSec (4KiB,Q1): 35
Power Consumption for 2.5inch Solid State Drive
Idle Time: 5.00 Watt
Random Read: 6.20 Watt
Random Write: 6.20 Watt
Sequential Read: 8.56 Watt
Sequential Write: 8.56 Watt
Random Read/Write: 5.90 Watt
Maximum: 8.56 Watt
Dimensions & Weight
Height: 5 Inch
Width: 7 Inch
Depth: 9 Inch
Weight: 1.10 Lbs
