UDM Technical Specifications
Ubiquiti UNIFI Base / UDR Active Cooling Stand Dream Machine
Dimensions: Ø 110 x 184.2 mm (Ø 4.33 x 7.25″)
Buttons: Reset
IDS/IPS Throughput: 850 Mbps
Processor: Arm Cortex-A57 Quad-Core at 1.7 GHz
System Memory: 2 GB DDR RAM
On-Board Flash Storage; 16 GB
Maximum Power Consumption: 26W
Supported Voltage Range: 100 – 240VAC
Power Method: AC Power Cord
Power Supply: Internal AC/DC Power Adapter (24V, 0.6A, 100 – 240VAC)
Power Save: Supported
Beamforming: Supported
TX Power*
2.4 GHz, 5 GHz
23 dBm, 26 dBm
Antenna: (1) Dual-Band, Quad-Polarity Antenna
Antenna Gain
2.4 GHz, 5 GHz
3 dBi, 4.5 dBi
Wi-Fi Standards: 802.11 a/b/g/n/ac/ac-wave2
BSSID: Up to 8 per Radio
Operating Temperature: -10 to 45° C (14 to 113° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: CE, FCC, IC
