UCSC-DBUN-C220-109 Technical Specifications
Cisco Systems Ucs C220 M3 SFF 2XE5-2665
General Information
Product Name Ucs C220 M3 SFF 2XE5-2665 2X8GB 9266CV 2X650W SD Rails
Manufacturer Part Number UCSC-DBUN-C220-109
Product Series C220 M3
Product Type Server
Controllers
Controller Type Serial SATA/600
6Gb/s SAS
RAID Supported Yes
RAID Levels 0, 1, 5, 6, 10, 50, 60
Memory
Standard Memory 16 GB
Memory Technology DDR3 SDRAM
Number of Total Memory Slots 16 DDR3 Slots
Network & Communication
Ethernet Technology Gigabit Ethernet
Power Description
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 650 W
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Intel Xeon
Processor Model E5-2665
Processor Core Octa-core (8 Core)
Processor Speed 2.40 GHz
Physical Characteristics
Form Factor Rack
Rack Height 1U Rack Mount
Height 1.7″
Width 16.9″
Depth 28.5″
Other Information
Product Family C220 M3
Cache 20 MB
Memory Card Reader Yes
64-bit Processing Yes
QuickPath Interconnect 8 GT/s
Hyper-Threading Yes
Number of Total Expansion Slots 2
Number of PCI Express x8 Slots 1
Number of PCI Express x16 Slots 1
VGA Yes
Network (RJ-45) Yes
Remote Management Yes
Total Number of USB Ports 5
Number of USB 2.0 Ports 2
Memory Card Supported SD
Memory Standard DDR3-1600/PC3-12800
