UCSC-C3X60-SVRN7 Technical Specifications
Cisco Systems Cisco C3X60 Server Node E5- FD
General Information
Product Name Cisco C3X60 Server Node E5- FD
Manufacturer Part Number UCSC-C3X60-SVRN7=
Product Type Server
Cisco UCS
Controllers
Controller Type 12Gb/s SAS
RAID Supported Yes
RAID Levels 0, 1, 5, 6, 10, 50, 60
Memory
Standard Memory 256 GB
Maximum Memory 512 GB
Memory Technology DDR3 SDRAM
Network & Communication
Ethernet Technology Gigabit Ethernet
Power Description
Input Voltage 120 V AC
230 V AC
Number of Power Supplies Installed 4
Maximum Power Supply Wattage 1050 W
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Intel Xeon
Processor Model E5-2695v2
Processor Core Dodeca-core (12 Core)
Processor Speed 2.40 GHz
Physical Characteristics
Form Factor Rack
Rack Height 4U Rack Mount
Height 6.9″
Width 17.5″
Depth 32″
