UCS-SPR-C240-E2 Technical Specifications
Cisco Systems Ucs C240M4SX with 2XE52620V3
General Information
Product Name Cisco Ucs C240M4SX with 2XE52620V3 2X8GB Mraid
Manufacturer Part Number UCS-SPR-C240M4-E2
Product Series C240 M4
Product Type Server
Controllers
Controller Type 12Gb/s SAS
Serial Attached SCSI (SAS)
Serial ATA
RAID Supported Yes
Memory
Standard Memory 16 GB
Memory Technology DDR4 SDRAM
Number of Total Memory 24 DDR4 Slots
Network & Communication
Ethernet Technology Gigabit Ethernet
Power Description
Input Voltage 120 V AC
230 V AC
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 1200 W
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Xeon
Processor Model E5-2620v3
Processor Core Hexa-core (6 Core)
Processor Speed 2.40 GHz
Physical Characteristics
Form Factor Rack
Rack Height 2U Rack Mount
Other Information
Product Family C240 M4
Cache 15 MB
Memory Card Reader Yes
64-bit Processing Yes
Chipset Manufacturer Intel
Chipset Model C610
QuickPath Interconnect 8 GT/s
Hyper-Threading Yes
Number of Total Expansion Slots 3
Number of PCI Express x8 Slots 2
Number of PCI Express x16 Slots 1
VGA Yes
Network (RJ-45) Yes
Remote Management Yes
Total Number of USB Ports 3
Number of USB 3.0 Ports 2
Maximum Turbo Speed 3.20 GHz
Memory Card Supported SD
Memory Standard DDR4-2133/PC4-17000
