UCS-SP-C240M5-S3 Technical Specifications
Cisco Systems SP C240 M5SX 2X4110 6X16GB
General Information
Product Name SP C240 M5SX 2X4110 6X16GB Memory Single Rank
Manufacturer Part Number UCS-SP-C240M5-S3
Product Series C240 M5
Product Type Server
Cisco UCS
Controllers
Controller Type 12Gb/s SAS
RAID Supported Yes
RAID Levels 0, 1, 5, 6, 10, 50, 60, JBOD
Display & Graphics
Graphics Controller Manufacturer ASPEED
Graphics Controller Model Pilot 4
Graphics Memory Capacity Up to 16 MB
I/O Expansions
Number of Total Expansion 26 Bays
Number of Internal 2.5″ Bays 26
Hot Swappable Bays Yes
Memory
Standard Memory 96 GB
Maximum Memory 9 TB
Memory Technology DDR4 SDRAM
Number of Total Memory Slots 24 DDR4 Slots
Number of Occupied Memory Slots 6
Intel Optane Memory Ready Yes
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
Power Description
Input Voltage 120 V AC
230 V AC
Number of Power Supplies Supported 2
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 1600 W
Redundant Power Supply Yes
Storage
Total Hard Drive Capacity No
Optical Drive Type No
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Xeon Silver
Processor Model 4110
Processor Core Octa-core (8 Core)
Processor Speed 2.10 GHz
Software
