UCS-SP-B200M4-A4T Technical Specifications
Cisco Systems B200M4 ADV4 with E52660V3
General Information
Product Name B200M4 ADV4 with E52660V3 16X16GB VIC 1340
Manufacturer Part Number UCS-SP-B200M4-A4T
Product Series B200 M4
Product Type Server
Cisco UCS
Controllers
Controller Type 12Gb/s SAS
Serial SATA/600
RAID Supported Yes
RAID Levels 0, 1
Display & Graphics
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200e
Graphics Memory Capacity Up to 8 MB
Memory
Standard Memory 256 GB
Maximum Memory 768 GB
Memory Technology DDR4 SDRAM
Memory Slots: 24 x DDR4 RAM Slots
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
Storage
Total Hard Drive Capacity No
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Intel Xeon
Processor Model E5-2660v3
Processor Core Deca-core (10 Core)
Processor Speed 2.60 GHz
Physical Characteristics
Form Factor Blade Server
Height 2″
Width 8″
Depth 24.4″
