UCS-FI-6248UP Technical Specification
Cisco 32 Ports Managed Switch Fabric UCS
Manufacturer: Cisco
Brand: Cisco
Product Type: Managed Switch
Technical Information
Total Number of Ports: 32
Enclosure Type: Rack-mountable 1U
Subtype: 10 Gigabit Ethernet
Ports: 12 x 10 Gigabit / FCoE SFP+
Performance
Throughput: 960 Gbps
MAC Address Table Size: 32,000 entries
Jumbo Frame Support: 9,216 bytes
Management & Protocols
Remote Management Protocol: RMON
Expansion / Connectivity
Interfaces: 1 x 1000Base-T RJ-45 management, 32 x SFP+
Expansion Slots: 1 (total) / 1 (free) x expansion slot
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Min Storage Temperature: -40 °F
Max Storage Temperature: 158 °F
Power
Power Device: Internal power supply – hot-plug
Power Redundancy Scheme: 1+1 (with optional power supply)
