UCS-EZ8-B200M4-VP Technical Specifications
Cisco Systems Ucs SP8 B200M4 Value +
General Information
Product Name Ucs SP8 B200M4 Value + with 2XE52 670V3
Manufacturer Part Number UCS-EZ8-B200M4-VP
Product Series B200 M4
Product Type Server
Cisco UCS
Controllers
Controller Type 12Gb/s SAS
Ethernet Technology: 40 Gigabit Ethernet
RAID Supported Yes
RAID Levels 0, 1
Memory
Standard Memory 256 GB
Maximum Memory 768 GB
Memory Technology DDR4 SDRAM
Number of Total Memory Slots 24 DDR4 Slots
Network & Communication
Ethernet Technology 40 Gigabit Ethernet
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Xeon
Processor Model E5-2670v3
Processor Core Dodeca-core (12 Core)
Processor Speed 2.30 GHz
Physical Characteristics
Form Factor Blade Server
Other Information
Product Family B200 M4
Cache 30 MB
Memory Card Reader Yes
64-bit Processing Yes
QuickPath Interconnect 9.60 GT/s
Hyper-Threading Yes
Number of Total Expansion Slots 2
Network (RJ-45) Yes
Maximum Turbo Speed 3.10 GHz
Memory Card Supported SD
SDHC
Memory Standard DDR4-2133/PC4-17000
