UCS-EZ-PERF-B200 Technical Specifications
Cisco Systems Ucs B200 M3 Blade Server
General Information
Product Name Cisco Ucs B200 M3 Blade Server with 2690 16X16GB Dual VIC
Manufacturer Part Number UCS-EZ-PERF-B200
Product Series B200 M3
Product Type Server
Controllers
Controller Type Serial SATA/600
6Gb/s SAS
RAID Supported Yes
RAID Levels 0, 1
Display & Graphics
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200e
I/O Expansions
Number of Total Expansion 2 Bays
Number of Internal 2.5″ Bays 2
Memory
Standard Memory 256 GB
Maximum Memory 384 GB
Memory Technology DDR3 SDRAM
Number of Total Memory Slots 24 DDR3 Slots
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Intel Xeon
Processor Model E5-2690
Processor Core Octa-core (8 Core)
Processor Speed 2.90 GHz
Software
Operating System No
Physical Characteristics
Form Factor Blade Server
Height 2″
Width 8″
Depth 24.4″
