SURT15KRMXLT Technical Specifications
APC Smart-UPS RT 15kVA RM 208V
Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS RT
Model :15KVA RM
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :Ethernet 10/100, RS-232
Remote Management Protocol :SNMP, HTTP
Expansion Slots
Expansion Slots :1 SmartSlot
Interface Provided
Interfaces :1 x management (RS-232) – 9 pin D-Sub (DB-9), 1 x management (Ethernet) – RJ-45, 1 x EPO (emergency power off)
Cable Details
Cables Included :Serial cable – external
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :On-line
Voltage Provided :AC 208-240 volt
Voltage Provided Margin :± 5%
Frequency Provided :50/60 hertz
UPS Output Waveform :Sinewave
Power Provided :12 kilograms per millimetere
Power Capacity (VA) :15000 volt ampere per kilogram 15000VA
Max Electric Current :85 ampere
Voltage Required :AC 208/240 volt
Input Voltage Range :AC 160 – 280 V
Frequency Required :40 – 70 hertz
Input Connector Type :Hardwire 3-wire (2PH + G)
Input Connector Qty :1
Output Connector Type :Power NEMA L6-20, Hardwire 3-wire (2PH + G), Power NEMA L6-30
Output Connector Qty :7
Power Device Features :Audible alarm, Emergency power off, Internal bypass, LED display
Power Output Connectors Details
Power Output Connectors Details :1 x hardwire 3-wire (2PH + G), 4 x power NEMA L6-20, 2 x power NEMA L6-30
Battery
Voltage Provided :192 volt
Run Time (Up To) :8.3 minute (time unit)
Load Type :At full load
Recharge Time :2.5 Hours
Run Time Details
Run Time (Up To) :8.3 min at full load
UPS
Batteries Qty :4
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Height (Rack Units) :12
Compliant Standards :UL 1778, UL 1449
Dimensions & Weight
Width :17 inch
Depth :30.4 inch
Height :21 inch
Weight :546.74 lbs
Dimensions & Weight (Shipping)
Shipping Width :24 inch
Shipping Depth :39.4 inch
Shipping Height :39 inch
Shipping Weight :692.24 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Sound Emission :50 dBA
