Refurbished ST10000NM0216 Technical Specifications
Seagate 10TB SAS Hard Drive
Specifications
Capacity 10TB/10,000GB
SED Model (512e) ST10000NM0216
Features
Helium Sealed-Drive Design With Wide Weld Yes
Digital Environmental Sensors Yes
Protection Information (T10 DIF) Yes
SuperParity Yes
PowerChoice™ Power/Performance Technology Yes
Low Halogen/Hot-Plug Support Yes
Cache, Multisegmented (MB) 256
Organic Solderability Preservative Yes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours) 2.5 Million
Reliabilility Rating @ Full 24×7 Operation (AFR) 0.35%
Non-recoverable Read Errors per Bits Read, Max 1 sector per 10E15
Power-On Hours 8760
512e Sector Size (Bytes per Sector) 512, 520, 528
4Kn Sector Size (Bytes per Sector) 4096, 4160,
Performance
Spin Speed(RPM) 7200RPM
Interface Access Speed (Gb/s) 12.0, 6.0, 3.0
Max. Sustained Transfer Rate OD (MB/s) 254MB/s
Random Read/Write 4K QD16 WCD (IOPS) 170, 370
Average Latency (ms) 4.16
Interface Ports Dual
Rotational Vibration @ 1500Hz (rad/s) 12.5
Power Consumption
Idle A (W) Averge 5.5W
Max Operating Power, Random Write (WCD) 4K/4Q RR50% / RW50% 9.0
Max Operating Power, Random Read 4K/16Q (W) 9.4
Power Supply Requirements +12 V and +5 V
Environmental
Temperature, Operating (°C) 5°C – 60°C
Vibration, Nonoperating: 10Hz to 500Hz (Grms) 2.27
Shock, Operating 2ms (Read/Write) (Gs) 70/40Gs
Shock, Nonoperating, 1ms/2ms (Gs)
