Refurbished SSM-4GE Technical Specifications
Cisco Security Services Module – expansion module
Header
Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco
Model :Security Services Module
Packaged Quantity :1
Networking
Type :Expansion module
Form Factor :Plug-in module
Connectivity Technology :Wired
Cabling Type :Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 10Base-T
Data Link Protocol :Ethernet, Gigabit Ethernet, Fast Ethernet
Data Transfer Rate :1 GBps
Status Indicators :Port transmission speed, Status, Link/activity, Link OK
Ports
Qty :4
Type :10/100/1000
Expansion Slots
Expansion Slots :4 (total) / 4 (free) x SFP
Interface Provided
Interfaces :4 x 1000Base-T – RJ-45
Slot Required
Compatible Slots :1 x expansion slot
Miscellaneous
Compliant Standards :UL 1950, FCC Part 15, CSA 22.2 No. 950, VCCI Class A ITE
Dimensions & Weight
Width :6.8 inch
Depth :11 inch
Height :1.5 inch
Weight :1.98 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 95%
