SSDPE21K100GA01 Technical Specifications
Intel Optane DC P4801X Series 100GB 3D Xpoint PCI Express 3.0 x4 NVMe (AES 256-Bits) U.2 2.5-inch Internal Solid State Drive (SSD)
Brand :Intel
Product Line :Intel Optane
Model :SSD DC P4801X Series
Packaged Quantity :1
Storage
Type :Solid state drive
Hard Drive
Hard Drive Type :Internal hard drive
Form Factor :2.5″, 2.5″ / U.2
Form Factor (metric) :6.4 cm, 6.4 cm / U.2
Form Factor (Short) :2.5″, U.2
Form Factor (Short) (metric) :6.4 cm, U.2
Storage Interface :U.2 PCIe 3.0 x4 (NVMe)
Interface :U.2 PCIe 3.0 x4 (NVMe)
Capacity :100 GB
SSD Technology :3D Xpoint (Optane)
Average Latency :10 microsecond
Internal Data Rate :2300 MBps
Internal Data Rate (Write) :1000 MBps
4KB Random Read :550000 IOPS
4KB Random Write :250000 IOPS
Non-Recoverable Errors :1 per 10^17
SSD Endurance :10.9 PB
Features :End-to-end data path protection, Enhanced Power Loss Data Protection, High Endurance Technology (HET), Temperature Monitoring and Logging
Interface Provided
Interfaces :1 x PCI Express 3.0 x4 (NVMe)
Bay Required
Compatible Bay :2.5″, 2.5″ / U.2
Power Consumption
Power Consumption :5 Watt (idle), 7 Watt (active)
