SRX550-645DP Technical Specifications
Juniper Networks SRX550 Services Gateway security appliance
Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :SRX550 Services Gateway
Packaged Quantity :1
RAM
Installed Size :2 GB
Flash Memory
Installed Size :2 GB, 2 GB
Optical Storage
Type :None
Performance
Performance :IPS throughput: 800 Mbps, Antivirus throughput: 300 Mbps, Connection rate: 27000 connections per second, Firewall throughput (IMIX): 1.7 Gbps, Firewall throughput (large packets): 5.5 Gbps
Capacity
Capacity :VPN tunnel interfaces: 456, Concurrent VPN tunnels: 2000, RIP routes: 712000, Security policies: 7256, BGP peers: 192, Virtual interfaces (VLANs): 3072, Concurrent sessions: 375000, BGP instances: 56, Static routes: 712000, Security zones: 96, Virtual routers: 48, BGP routes: 712000, RIP instances: 56, IPSec VPN tunnels: 2000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Connectivity Technology :Wired
Data Link Protocol :Fast Ethernet, Gigabit Ethernet, Ethernet
Routing Protocol :MSDP, MPLS, IGMPv2, PIM-SM, PIM-SSM, OSPFv3, PIM-DM, RIP-1, IGMP, OSPF, BGP, IGMPv3, RIP-2, DVMRP, ECMP
Switching Protocol :Ethernet, Frame Relay
Network / Transport Protocol :FTP, DHCP, IMAP, POP3, SMTP, IPSec, PPPoE
Features :MPLS VPN, DHCP support, Intrusion Prevention System (IPS), IP address filtering, DoS attack prevention, DDos attack prevention, Firewall protection, Jumbo Frames support, Quality of Service (QoS), Content filtering
Compliant Standards :IEEE 802.3af, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1x
Expansion Slots
Expansion Slots :4 (total) / 4 (free) x SFP (mini-GBIC), 6 (total) / 6 (free) x Gigabit-Backplane Physical Interface Module (GPIM), 2 (total) / 2 (free) x Mini-Physical Interface Module (Mini-PIM)
Interface Provided
Interfaces :2 x USB – Type A, 6 x 1000Base-T – RJ-45
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Optional
Installed Qty :1
Max Supported Qty :2
Power Provided :645 watt
Power Consumption Operational :122 watt
Miscellaneous
Height (Rack Units) :2
Encryption Algorithm :256-bit AES, SHA-1, MD5, Triple DES, DH, IKE, PKI, DES
Authentication Method :XAUTH (RADIUS, LDAP, Active Directory), LDAP, SecurID, RADIUS
Compliant Standards :ICES Class B, CS-03, DOC, CTR 21, EN55022 Class B, UL 60950-1, EN 60950-1, CSA, VCCI Class B ITE, FCC Class B certified
Dimensions & Weight
Width :17.5 inch
Depth :18.2 inch
Height :3.5 inch
Weight :22.05 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :10 – 90% (non-condensing)
