SRT192BPUS Technical Specifications
APC Smart-UPS SRT 192V 5kVA and 6kVA Battery Pack
Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS SRT
Model :192V 5kVA and 6kVA Battery Pack
Packaged Quantity :1
Output
Battery Output Voltage 192V
Batteries & Runtime Battery type
Maintenance-free sealed Lead acid battery with suspended electrolyte : leakproof
Battery mounting
Stand alone battery stack
Expected Battery Life (years) 3 – 5
RBC Quantity 2
Battery Volt-Amp-Hour Capacity 1920
Physical
Maximum Height
17.0inches (432MM, 43.2CM)
Maximum Width
5.1inches (130MM, 13.0CM)
Maximum Depth
26.88inches (683MM, 68.3CM)
Net Weight
200.2lbs. (90.81KG)
Shipping weight
223.3lbs. (101.29KG)
Shipping Height
16.54inches (420MM, 42.0CM)
Shipping Width
23.63inches (600MM, 60.0CM)
Shipping Depth
39.38inches (1000MM, 100.0CM)
Color Black
Units per Pallet 1.0
Environmental
Operating Temperature
32 – 104 °F (0 – 40 °C)
Operating Relative Humidity
0 – 95 (no %
Operating Elevation
0-10000ft (0-3000meters)
Storage Temperature
-15 – 45 °C
Storage Relative Humidity
0 – 95 (no %
Storage Elevation
0-15000ft (0-4500meters)
