SMT1000C Technical Specifications
APC Smart-UPS 1000VA LCD UPS 700W 1000VA with APC SmartConnect
Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS
Model :1000VA LCD
Bundled with :APC SmartConnect
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :USB
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (USB) – 4 pin USB Type B
Cable Details
Cables Included :Power cable – integrated – 6 ft
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :Line interactive
Voltage Provided :AC 120V
Voltage Provided Margin :± 5%
Frequency Provided :50/60 hertz
UPS Output Waveform :Sinewave
Power Provided :700 watt
Power Capacity (VA) :1000 volt ampere per kilogram 1000VA
Voltage Required :AC 120 volt
Input Voltage Range :AC 82 – 144 V
Input Voltage Range (Adjustable) :AC 75 – 154 V
Frequency Required :50/60 hertz
Input Connector Type :Power NEMA 5-15P
Input Connector Qty :1
Output Connector Type :Power NEMA 5-15
Output Connector Qty :8
Surge Suppression :Yes
Surge Energy Rating :680 joules
Circuit Protection :Circuit breaker
Efficiency :97.8% at 50% Load, 98.3% at 75% Load, 98.4% at 100% Load, 96.2% at 25% Load
Power Device Features :Cold-start function, Hot-swappable batteries, Automatic self-test, Audible alarm, LED indicators, Automatic Voltage Regulation (AVR), LCD display, Energy meter
Power Output Connectors Details
Power Output Connectors Details :8 x power NEMA 5-15
Battery
Run Time (Up To) :6 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Lead Acid Battery Features :Leak-proof, Maintenance free, Sealed
Run Time Details
Run Time (Up To) :7 min at 600 Watts, 10 min at 500 Watts, 25 min at 300 Watts, 6 min at full load, 45 min at 200 Watts, 100 min at 100 Watts, 19 min at half load, 183 min at 50 Watts, 15 min at 400 Watts
UPS
Batteries Qty :1
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Height (Rack Units) :0
Equipment Protection Value :150000 US Dollars
Compliant Standards :UL 1778, FCC Part 15 B, RoHS, ICES-003, CSA C22.2 No. 107.1, REACH, CSA, UL 1449
Environmental Standards
ENERGY STAR :Yes
Dimensions & Weight
Width :6.7 inch
Depth :17.3 inch
Height :8.6 inch
Weight :0.71 ounce
Dimensions & Weight (Shipping)
Shipping Width :13 inch
Shipping Depth :23.2 inch
Shipping Height :13 inch
Shipping Weight :49.91 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :41 dBA
