SM-X-16FXS/2FXO= Technical Specifications
Cisco High-Density Analog Voice Service Module SM-X-16-FXS/2FXO – expansion module
Brand: Cisco
Product Line: Cisco High-Density Analog Voice Service Module
Model: SM-X-16-FXS/2FXO
Manufacturer: CISCO DS HARDWARE DIRECT
Network & Communication
Compliant Standards: G.711, G.726, G.729a
Connectivity Technology: Wired
Form Factor: Plug-in module
Network Standard: DHCP, DNS, RTCP, RTP
Product Type: Expansion module
Remote Management: HTTP, SNMP, Telnet, TFTP
Status Indicators: Status
Conectivity
Interface Provided: 16 x FXS – RJ-21, 2 x FXO – RJ-21
Port Quantity: 16
Network & Adapter Ports: FXS
Power
Power Consumption Operational: 70.32 watt
Technical Information
Max Operating Temperature: 104 degree Fahrenheit
Min Operating Temperature: 32 degree Fahrenheit
Product Information
Packaged Quantity: 1
Ports (2nd) Quantity: 2
Ports (2nd) Type: FXO
Dimensions & Weight
Height: 1.6 inch
Weight: 31.74 ounce
Width: 7.4 inch
Depth: 7.6 inch
Physical Characteristics
Color Category: Silver
